Pharmaceutical Nozzle Jet Granulator Spray Drying Machine

Product Details

Place of Origin: China

Brand Name: Xin ShengMan

Certification: CE and ISO9001

Model Number: LPG-5/25/50/100/150/200-2000

Payment & Shipping Terms

Minimum Order Quantity: 1Set

Price: USD10000-USD300000

Packaging Details: Plywood cases

Delivery Time: 60-90days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 10sets/Month

Get Best Price
High Light:

nozzle jet spray drying machine

,

granulator spray drying machine

,

plc vacuum ceramic spray dryer

Warranty:
1 Year
Type:
Spray Dryer
Certificate:
ISO9001 And CE
Service:
Engineers Available To Service Machinery Overseas
Heating Source:
Electrical, Oil, Coal, Steam
Power (Kw):
Depend On The Model
Steel Material:
Stainless Steel 304, Carbon Steel, Or Q235A Steel
Control:
PLC Touch Screen
Package:
Wooden Case
Dimension (L*W*H):
Depend On The Model
Application:
Industrial
New:
100% New
Supplier:
Chinese Factory
Warranty:
1 Year
Type:
Spray Dryer
Certificate:
ISO9001 And CE
Service:
Engineers Available To Service Machinery Overseas
Heating Source:
Electrical, Oil, Coal, Steam
Power (Kw):
Depend On The Model
Steel Material:
Stainless Steel 304, Carbon Steel, Or Q235A Steel
Control:
PLC Touch Screen
Package:
Wooden Case
Dimension (L*W*H):
Depend On The Model
Application:
Industrial
New:
100% New
Supplier:
Chinese Factory
Pharmaceutical Nozzle Jet Granulator Spray Drying Machine

pharmaceutical spray drying nozzle jet spray dryer Spray dryer granular machine





Spray dryer is one of the most popular industrial drying method, it could dried the powder directly from liquid o paste shape material.

The working principle is: cold air is filtered through the filter, then enters the heater, is heated to a certain temperature, and then enters the air distributor at the top of the spray tower, and the hot air spirally flows to the bottom of the tower. The liquid is pumped to the centrifugal atomizer at the top of the tower body, and the liquid is torn into extremely small mist droplets. The liquid droplets and the hot air are in parallel contact, and the heat exchange is fully performed. The water content is rapidly vaporized and evaporated, and dried in a very short time as a finished product. The finished product is separated by a cyclone and discharged, and the exhaust steam is discharged by an induced draft fan.



Pharmaceutical Nozzle Jet Granulator Spray Drying Machine 0





Pharmaceutical Nozzle Jet Granulator Spray Drying Machine 1



Main Features





(1) Fast drying: liquid or wet raw material after atomization, significantly increased surface area, in the hot air flow, instantaneous evaporation can be 95% ~98% moisture, to complete the drying time only a few seconds, and especially suitable for drying of thermal sensitive material.

(2) Excellent drying effect: Finished products with good uniformity, fluidity and solubility, the product high purity, good quality.

(3) Production process is simple, convenient operation and control. For material which moisture content 40-60% (special material even moisture contents 90%) of the liquid to a dry powder products, dried without crushing and screening, and product purity. Product size, density and moisture can be adjusted( within a certain range) by changing the operating conditions.









Pharmaceutical Nozzle Jet Granulator Spray Drying Machine 2






Technical parameters


Model PLG
5 25 50 100 150 200-2000
inlet temperatyre ℃ 140-350 automatically controlled
outlet temperatyre ℃ 80-90
Max water evaporation capacity  kg/h 5 25 50 100 150 200-2000
centrifugal spraying nozzle transmission mode    compressed air       transmission mechaical transmission
rotation speed (r.p.m) 25000 18000 18000 18000 15000 8000-15000
spraying desc diameter (mm)                50 100 120 140 150 180-340
max electric heating power  (kw)                 9 36 63 81 99 settled by customer
overall dimensions        1.8*0.93*2.2 3*2.7*4.26 3.7*3.2*5.1 4.6*4.2*6 5.5*4.5*7 depends on tryer
dried powder collection               ≥95 ≥95 ≥95 ≥95 ≥95 ≥95



Pharmaceutical Nozzle Jet Granulator Spray Drying Machine 3



Applications




Centrifugal spray dryer is the most widely used process in liquid shaping technology. Can be used for:

Chemical industry: sodium fluoride (potassium), basic dyes and pigments, dye intermediates, compound fertilizers, formaldehyde silicic acid, catalysts, sulfuric acid, amino acids, white carbon black, etc.

Plastic resin: AB, ABS emulsion, urinary formaldehyde resin, phenolic resin, dense rubber (urea) formaldehyde resin, polyethylene, polyvinyl chloride, etc.

Food industry: fat-rich milk powder, gluten, cocoa milk powder, milk substitutes, blood hunting powder, egg white (yellow), etc.

Food and plants: oats, chicken juice, coffee, instant tea, flavored meat, protein, soybean, peanut protein, hydrolysate, etc.

Sugars: corn syrup, corn starch, glucose, pectin, maltose, potassium sorbate, etc.

Ceramics: alumina, ceramic tile materials, magnesium oxide, talcum powder, etc.



Pharmaceutical Nozzle Jet Granulator Spray Drying Machine 4
