Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering

Product Details

Place of Origin: CHANGZHOU

Brand Name: Xin Shengman

Certification: ISO9001 and CE

Model Number: Hollow Paddle Dryer

Payment & Shipping Terms

Minimum Order Quantity: 1 pc

Price: USD1,5000-USD20,3000

Packaging Details: Plywood cases

Delivery Time: 30-60 days

Payment Terms: T/T

Supply Ability: 6sets/Month

Get Best Price
High Light:

hollow paddle dryer 304 stainless steel

,

continuous vacuum blade hollow paddle dryer

,

sludge dewatering vacuum paddle dryer

Name:
Paddle Dryer Machine
After-sales Service:
Engineers Available To Service Machinery Overseas
Warranty:
1 Year
Material:
304 Stainless Steel
Heating Method:
Hot Water/steam/oil
Capacity:
As U Requirement
Heating Source:
Steam, Electricity, Etc
Condition:
New
Application:
Industry
Type:
Sludge Drying Machine
Name:
Paddle Dryer Machine
After-sales Service:
Engineers Available To Service Machinery Overseas
Warranty:
1 Year
Material:
304 Stainless Steel
Heating Method:
Hot Water/steam/oil
Capacity:
As U Requirement
Heating Source:
Steam, Electricity, Etc
Condition:
New
Application:
Industry
Type:
Sludge Drying Machine
Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering

Trending Now Continuous Vacuum Blade Paddle Dryer for Sludge Dewatering



Structure introduction:

The main structure is a W-shaped shell with a jacket, which is equipped with a pair of hollow low-speed rotating hollow shafts. A number of mixing blades are welded on the shaft. The jacket and the hollow mixing blades are all equipped with heat carriers, and the two heating surfaces heat the materials at the same time. The heat carrier is usually fed from the middle of the dryer and discharged from the other side through the surface of the material layer in the agitated state.

Wedge-shaped hollow blades are densely arranged on the hollow shaft, and the thermal medium flows through the blades through the hollow shaft. The unit effective volume has a large heat transfer area. The temperature of the thermal medium ranges from - 40 ° C to 320 ° C, which can be water vapor or liquid type: such as hot water, heat transfer oil, etc. Indirect conduction heating does not carry air to take away heat. Heat is used to heat materials. The heat loss is only the heat dissipation to the environment through the insulation layer of the reactor body. The heat transfer surface of the wedge-shaped blade has the function of self-cleaning. The relative movement of the material particles and the wedge-shaped surface can wash off the attached materials on the wedge-shaped surface, so that the clean heat transfer surface is kept in motion all the time.



Working Principle


The cylinder is a jacket structure in which hot steam circulates inside. During operation, water vapor is introduced into the jacket, hollow shaft, and blade to provide the heat required for drying; a very small amount of air is introduced into the dryer and used as a carrier for the steam (or organic steam) that evaporates during drying; the material enters the machine from the feed port, and is conveyed by the hollow blade to the discharge port for discharging. The material is heated and evaporated by the hollow blade and the jacket during the conveying process to be dried. The heat transfer surface of the wedge blade has a self-cleaning function. The relative motion between the particles and the wedge surface produces a washing effect that washes away the adhering material on the surface of the blade, which allows the material to have a long residence time and a high fill factor.

Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering 0

Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering 1





Technical parameters



Model KJG-2.7 KJG-24 KJG-52 KJG-81 KJG-110
Heat transfer area 2.7 24 52 81 110
effective volume 0.06 1.53 3.96 6.43 9.46
revolution 15-30 10-20 10-20 5-15 5-10
power 2.2 11 30 55 95
width of dryer body 306 1118 1474 1828 2210
total width 736 1474 1854 2286 2668
length of dryer body 1956 3454 5258 6020 6122
total length 2972 6147 8306 9678 9880
distance between feeding and disharging 1752 3150 4954 5562 5664
height in center 380   1066 1220 1220
total height 762   2032 2464 2668
steam inlet (2) 3/4 (2) 1 (2) 11/2 (2) 11/2 (2) 2
water outlet (2) 3/4 (2) 1 (2) 11/2 (2) 11/2 (2) 2





Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering 2





Applications



Petrochemical industry: polyolefin powder, polycarbonate resin, high and low-density polyethylene, linear low-density polyethylene, polyacetal granules, nylon 6, nylon 66, nylon 12, acetate, polyphenylene sulfide, propylene base resin, polypropylene, engineering plastics, polyvinyl chloride, polyvinyl alcohol, polystyrene, polyester, polyoxymethylene, styrene-acrylonitrile copolymerization, ethylene-propylene copolymerization.


Environmental protection industry: sludge, electroplating sewage sludge, boiler soot, sugar factory waste residue, pharmaceutical factory waste residue, MSG factory waste residue, coal ash.


Feed industry: soy sauce residue, bone-based feed, distiller's grains, food scraps, apple pomace, orange peel, soybean meal, chicken bone feed, fish meal, feed additives, bio-sludge.


Food industry: starch, cocoa beans, corn kernels, salt, modified starch, medicines.


Chemical industry: soda ash, NPK compound fertilizer, kaolin, bentonite, white carbon black, carbon black, phosphogypsum, calcium sulfate, calcium nitrate, magnesium carbonate, sodium cyanide, oxidized sodium fluoride, aluminum hydroxide, barium sulfate, calcium carbonate, molecular sieves, dyes, saponins.




Continuous Vacuum Blade Hollow Paddle Dryer For Sludge Dewatering 3

Paddle dryer has following main features:

1.Compact structure, large efficient heat transfer area, and small occupied

area.

2.Stirring is uniform, heat efficiency is high, and drying efficiency is good.

3.Paddle shafts can mesh each other, and have self-clean function, it can

avoid material stick on the wall.

4.Energy consumption is low, and operating cost is low

5.Little dust carried out, little material loss

6.Heat indirectly, material can not be polluted

7.Rotary speed of paddle shaft is low, it will not destroy the shape and

property of product

8.Operating flexibility is large, running is stable and reliable.
