Western Medicine Dry Granulation Roll Compactor for strict process requirements

Product Details

Place of Origin: changzhou

Brand Name: Shengman

Certification: CE

Model Number: LG

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: USD30,000-300,000

Packaging Details: exporting package

Delivery Time: 30-90 days

Payment Terms: T/T

Supply Ability: 1-10sets/month

Get Best Price

Product Details

Product Description

Highlight:

Features:	No Waters And Solvents	Machine Type:	Dry Granulator
Capacity:	Required By Customers	Optional Device:	Micro Feeder Device
Supplier:	Chinese Factory	Control System:	PLC
Feeding Type:	Horizontal Feeding Type	Warranty:	One Year
Material:	SS304, 316L	Core Selling Point:	Famous Brand Plc
Applicable Industry:	Pharma, Chemical, Food Industry	Advantages:	Strict Process Requirements
Package:	Wooden Case Or Wooden Pallet

Features:	No Waters And Solvents
Machine Type:	Dry Granulator
Capacity:	Required By Customers
Optional Device:	Micro Feeder Device
Supplier:	Chinese Factory
Control System:	PLC
Feeding Type:	Horizontal Feeding Type
Warranty:	One Year
Material:	SS304, 316L
Core Selling Point:	Famous Brand Plc
Applicable Industry:	Pharma, Chemical, Food Industry
Advantages:	Strict Process Requirements
Package:	Wooden Case Or Wooden Pallet

Western Medicine Dry Granulation Roll Compactor for strict process requirements

Western Medicine Dry Granulation Roll Compactor for strict process requirements

The dry granulation process is used to form granules without using a liquid solution because the product to be granulated may be sensitive to moisture and heat. Forming granules without moisture requires compacting and densifying the powders.

The dry powders can be compressed using a conventional tablet machine or, more usually, a large heavy-duty rotary press can be used. This process is often known as ‘slugging’, the compact made in the process (typically 25 mm diameter by about 10–15 mm thick) being termed a ‘slug’. A milling device is suitable for breaking the compacts. Roller compactors Roller compaction is an alternative gentler method, the powder mix being squeezed between two rollers to form a compressed sheet. The sheet normally is weak and brittle and breaks immediately into flakes. These flakes need gentler treatment to break them into granules. This can further be milled into desired particle size.

Model	LG100	LG100E	LG160	LG200	LG240	LG360
Capacity (kg/h)	1.5-15	12-40	50-150	100-240	160-320	360-720
Rated power (kw)	3.47	3.53	7.24	11.37	15.94	32.55
Roller size (D*W)	100*25	100*40	160*50	200*75	240*100	360*150

For large production scale application, we provide double-supporting roller model

Model	LGS200	LGS240	LGS360	LGS500
Capacity (kg/h)	200-400	300-640	1200-2000	1500-3000
Rated power (kw)
Roller size (D*W)

Roller Compactor For Dry Granulation has the following features:

• In compliance with cGMP guidelines
• Contact parts are made of S.S 304 or S.S. 316 except rollers
• All covers are designed to obtain dust-free operation
• Feed screw is steplessly driven through variable frequency drive.
• Hard chome plated & mirror finished compacting rolls made of tools steel
• Pre-compaction chamber guides the product to rolls without any slippage or leakage.
• Electrical interlocking between main roll drive and feed screw drive
• Water Jacketing arrangement
• Hydraulic Power Pack system
• Inverter for rolls and milling device
• PLC system as per 21 CFR part 11 (optional)

The dry granulation machine is always called Roller Compactor, Roll Compactor, Dry Granulator and so on. Dry granulator is one of the main granulation equipment commonly used in pharmaceutical factories, health product factories, food factories, and chemical factories.

Why Choose Us:
We are a leading Chinese manufacturer specializing in dry granulation equipment. With extensive experience in custom engineering solutions, we ensure that each machine meets your unique production requirements, improving efficiency and product quality.

Call-to-Action:
Contact us today to discuss your production needs and get a customized dry granulation solution!
