High Performance Roller Compactor Dry Granulator for Powder Materials

Advanced Dry Granulation Solution for Pharmaceutical, Chemical and Food Production

The Roller Compactor Dry Granulator is an innovative powder processing machine that transforms fine powder materials into uniform granules through high-pressure mechanical compaction.

Unlike traditional wet granulation equipment, this dry granulation system does not require water, organic solvents, binders, or drying procedures. It provides a more efficient and environmentally friendly solution for manufacturers producing pharmaceutical, chemical, food, and nutraceutical products.

The equipment is particularly suitable for heat-sensitive, moisture-sensitive, and high-value active ingredients, where maintaining material stability and quality is critical.

Working Process

The powder material is continuously fed into the compaction chamber through a precision feeding system.

Under controlled hydraulic pressure, two counter-rotating rollers compress the powder into dense sheets (ribbons). The compacted sheets are then pre-crushed and processed through a two-stage milling system to achieve the required granule size.

The complete process includes:

Powder Feeding → High Pressure Compaction → Ribbon Breaking → Milling → Granule Collection

The dry granulation process avoids thermal stress and moisture exposure, ensuring consistent product quality.

Models

For large production scale application, we provide double-supporting roller model

• Outstanding Features

  1. Stable Material Properties

  The granulation process relies on mechanical force rather than chemical binders. The molecular structure and active components of the material remain unchanged.

  It is ideal for:

  • Heat-sensitive drugs
  • Moisture-sensitive ingredients
  • Active pharmaceutical ingredients (API)
  • High-value powders

  ---

  2. High Productivity & Low Energy Consumption

  Compared with conventional wet granulation methods, the Roller Compactor eliminates:

  • Binder preparation
  • Wet mixing
  • Drying process
  • Additional drying equipment

  This helps reduce production costs and improve manufacturing efficiency.

  Granulation yield can reach:

  Up to 85% for 8–60 mesh granules

  ---

  3. Precise Hydraulic Pressure Control

  The built-in hydraulic system provides stable and adjustable compression force.

  Operators can easily control:

  • Granule hardness
  • Granule density
  • Tabletability
  • Final particle characteristics

  Meeting different formulation requirements.

  ---

  4. Flexible Roller Surface Options

  Different roller designs are available according to material properties:

  Checker Roller

  Suitable for materials requiring stronger gripping force.

  Groove Roller

  Suitable for general powder compaction applications.

  Smooth Roller

  Suitable for materials requiring gentle compression.

  ---

  5. Hygienic and Easy Maintenance Design

  The equipment adopts a compact structure with fewer connecting parts.

  Advantages include:

  ✔ Fast disassembly
  ✔ Easy cleaning
  ✔ Reduced maintenance time
  ✔ Improved production efficiency

  The installation and disassembly process can be completed within approximately 8 minutes.

  ---

  6. Reliable Sealing System

  The fully enclosed structure prevents:

  • Powder leakage
  • External contamination
  • Material loss

  Ensuring a cleaner production environment and safer operation.

  ---

  7. Intelligent Integrated Control System

  The control cabinet is integrated with the main machine, simplifying:

  • Installation
  • Commissioning
  • Operation management

  The system provides stable and user-friendly operation.

Applications:

• Tablet manufacturing in pharma industry
• Granulation of chemical powders
• Food supplement production
• Pilot-scale and industrial-scale operations

Why Choose Our Roller Compactor?

✔ Advanced dry granulation technology
✔ No water and no drying process
✔ Suitable for sensitive materials
✔ Adjustable compression pressure
✔ Uniform granule size
✔ High production efficiency
✔ Low energy consumption
✔ Easy operation and maintenance
✔ Long service life
