Product Details
Place of Origin: China
Brand Name: JingSu ShengMan
Certification: CE and ISO9001
Model Number: FZG/YZG
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD20000-USD300000
Packaging Details: Plywood Cases
Delivery Time: 60-90days
Payment Terms: L/C, T/T
Supply Ability: 10sets
Condition: |
New |
Warranty: |
1 Year |
Heating Source: |
Hot Water/Steam/Thermal Oil |
Layers Of Baking: |
4-12 |
Quantity Of Baking Tray: |
4-48 |
Size Of Baking Tray: |
Customizable |
Temp: |
35-150℃ |
Condensor: |
Choosed By Customer |
Weight: |
250-3200kg |
Material: |
Stainless Steel |
Condition: |
New |
Warranty: |
1 Year |
Heating Source: |
Hot Water/Steam/Thermal Oil |
Layers Of Baking: |
4-12 |
Quantity Of Baking Tray: |
4-48 |
Size Of Baking Tray: |
Customizable |
Temp: |
35-150℃ |
Condensor: |
Choosed By Customer |
Weight: |
250-3200kg |
Material: |
Stainless Steel |
Square and Round Static Vacuum Drying Oven for Herbal Extract in Pharmaceutical Industry
Scope of application
It is suitable for drying heat sensitive raw materials that can decompose and polymerize and metamorphose at high temperature .It is wide used in pharmaceutical , chemical ,foodstuff electronic industries.
Principle
Vacuum drying is to put raw material under the state of vacuum for heating and drying. If use vacuum to pump air and humidity out, the dry speed will be faster.
Note: if use condenser, the solvent in raw material can be recovered. If the solvent is water, condenser might be canceled and the investment and every could be saved. it use SK series water ring vacuum pump sets, condensate can not be used and the investment could be saved .
Features
1. Under the condition of vacuum, the boiling point of raw material will decrease and make the pushing force become greater. Therefore for a certain amount of heat radiation, the conducting area of evaporator can be saved.
2. The heat source for operation of evaporation may be low pressure steam or surplus heat steam.
3. The heat loss of evaporator is less;
4. Before drying, the treatment of disinfection may be carried out. During the period of drying, there is no impurity material. It is in conformity with the requirement of GMP;
5. It belongs to static drier. So the shape of raw material to be dried can not be destroyed.
Technical parameters
| Inner Size mm | φ600*976 | φ1000*1527 | 1500*1060*1220 | 1500*1800*1220 |
| Outer Size mm | 1135*810*1020 | 1693*1190*1500 | 1924*1720*1513 | 1924*2500*1513 |
| layers of baking | 4 | 6 | 5 | 12 |
| Interval mm | 81 | 102 | 122 | 122 |
| size of baking tray mm | 310*600*45 | 520*410*45 | 460*640*45 | 460*640*45 |
| Temp | 35-150 | 35-150 | 35-150 | 35-150 |
| weight | 250 | 800 | 1400 | 3200 |
Note: The above data is for reference only. If having special requirements, the factory can provide the service of consultation and design.
Pre-service:
As a good and rich experience supplier, we should offer customer the best quality and best price of the machine.
1. Introduce the suitable product to the customer in detail, answer the question raised by customer carefully.
2. Make the suitabe project as the customer requirement and make sure the machine is suitable for the material.
Sale service:
(1). Ensure product with high quality and pre-commissioning before delivery. (2). Delivery on time. (3). Provide full set of documents as customer’s requirements.
After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators.
4. Examine the equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship.
Service commitment:
1. Provide clients one-year warranty to make sure the machine work well.
2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.
3. Send every client a preferential quotation.
