SUS304 300-3600L Vacuum Harrow Dryer Sludge Drying Equipment

Factory Price Environmental Protect Vacuum Harrow Dryer For Sludge

Product

The vacuum paddle dryer is new type high-efficiency horizontal vacuum drying equipment. It adopts jacketed structure, and the jacket can be heated by steam, hot water or conduction oil. The jacket transfers the heat to the inner wall of the shell via conduction or radiation. The dried materials are added into the dryer through an opening in the middle of the machine shell. Constant stirring of the revolving harrow causes the materials move back and forth. The surface contacting with the inner wall of the shell constantly updates, resulting in high drying rate and uniform finished products.

The dryer is simple to operate, easy control the material, greatly reducing the labor intensity of workers, also reduce the material pollution in the drying process at the same time.

1. The reducer: the reducer installed in the right side of the machine. The motor was driven by the pulley and the V-belt to the gear unit, the spindle rotation to the rake teeth, and finally the cylinder rotated and get speed of 6~ 10 r / min.

2. The motor base device: The motor was mounted on the right side of the activity board, can be adjusted up and down, so that the V-belt tight fit.

4. Electrical control device (EU standard): All the electrical control, buttons, lights are installed in the control box, the operation can be controlled based on the panel text instructions. The positive and the reversing rotating direction of the stirring shaft can be adjusted according to the characteristics of the material. Generally, it can be controlled in about 5 minutes (ie, after stopping for 5 minutes, then reversing for 5 minutes).

5. Sealed structure: The spindle at both ends are sealed with PTFE , sealed in a vacuum to achieve a good sealing effect.

Technical parameters

Note: The above data is for reference only. If having special requirements, the factory can provide the service of consultation and design.

Applications

Sale service:
(1). Ensure product with high quality and pre-commissioning before delivery. (2). Delivery on time. (3). Provide full set of documents as customer’s requirements.

After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators.
4. Examine the equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship.

Service commitment:
1. Provide clients one-year warranty to make sure the machine work well.

2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.

3. Send every client a preferential quotation.
