Product Details
Place of Origin: China
Brand Name: JingSu ShengMan
Certification: CE and ISO9001
Model Number: FLG
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD20000-USD300000
Packaging Details: Plywood Cases
Delivery Time: 60-90days
Payment Terms: L/C, T/T
Supply Ability: 10sets
Condition: |
New |
Warranty: |
1 Year |
Voltage: |
Customized |
Machine Type: |
Granulator |
Heating System: |
Steam,Electronic,oil |
Standard: |
GMP |
Material: |
Stainless Steel |
Power Of Fan: |
4-22 Kw |
Dimension: |
Requirement From Customer |
Application: |
Pharmaceutical, Food, Chemical |
Condition: |
New |
Warranty: |
1 Year |
Voltage: |
Customized |
Machine Type: |
Granulator |
Heating System: |
Steam,Electronic,oil |
Standard: |
GMP |
Material: |
Stainless Steel |
Power Of Fan: |
4-22 Kw |
Dimension: |
Requirement From Customer |
Application: |
Pharmaceutical, Food, Chemical |
Spray Drying Granulator Multi-Purpose The Pharmaceutical Industry Fully Automatic Visual Design Pelletizer
PGL Series Spray Drying Granulator Product Overview:
1. The drying speed is fast, and the surface area of the material liquid is greatly increased after atomization. In the hot air flow, 95% -98% of the water can be evaporated instantly, and the time to complete the drying only needs ten to tens of seconds, especially Suitable for drying heat sensitive materials.
2. All products are spherical particles with uniform particle size, good fluidity, good solubility, high product purity and good quality.
3. It has a wide range of applications. According to the characteristics of the material, it can be dried with hot air or granulated with cold air, which has strong adaptability to the material.
4. Simple and stable operation, convenient control, easy to realize automatic operation.
Technical Parameters
| Item | Unit type | PGL-3B | PGL-5B | PGL-10B | PGL-20B | PGL-30B | PGL-80B | PGL-120B | |
| fluid extract | min | kg/h | 2 | 4 | 5 | 10 | 20 | 40 | 55 |
| max | kg/h | 4 | 6 | 10 | 30 | 40 | 100 | 140 | |
| boiling capacity | min | kg/batch | 2 | 6 | 15 | 30 | 60 | 100 | 150 |
| max | kg/batch | 6 | 15 | 30 | 80 | 160 | 250 | 450 | |
| specific gravity of liquid | kg/L | ≤1.30 | |||||||
| volume of material container | L | 26 | 50 | 220 | 420 | 620 | 980 | 1600 | |
| dia.of container | mm | 400 | 550 | 770 | 1000 | 1200 | 1400 | 1600 | |
| power of induced-draft fan | kw | 4 | 5.5 | 7.5 | 15 | 22 | 30 | 37 | |
| power of induced-draft fan | kw | 0.35 | 0.75 | 0.75 | 1.2 | 2.2 | 2.2 | 4 | |
| steam | consumed amount | kg/h | 40 | 70 | 99 | 210 | 300 | 366 | 465 |
| pressure | Mpa | 0.40-0.60 | |||||||
| prwer of electroc heater | kw | 9 | 15 | 21 | 25.5 | 51.5 | 60 | 75 | |
| compressed air | consumed amount | m3/min | 0.9 | 0.9 | 0.9 | 0.9 | 1.1 | 1.3 | 1.8 |
| pressure | Mpa | 0.30-0.60 | |||||||
| temperature of operation | ℃ | automatic adjustment from room temperature to 130℃ | |||||||
| moisture of product | % | ≥0.5 decided in accordance with detaied material | |||||||
| yield of material | % | ≥99 | |||||||
| noise of equiment | dB | <70 | |||||||
| size of main machine | Ø | mm | 400 | 550 | 770 | 1000 | 1200 | 1400 | 1600 |
| H1 | mm | 940 | 1050 | 1070 | 1180 | 1620 | 1620 | 1690 | |
| H2 | mm | 2100 | 2400 | 3150 | 3150 | 3630 | 4120 | 5050 | |
| H3 | mm | 2450 | 2750 | 3700 | 3700 | 4100 | 4770 | 5800 | |
| B | mm | 740 | 890 | 1420 | 1420 | 1600 | 1820 | 2100 | |
◆Fluidextract,vitamin,animal glue,vegetable glue,barm,protease,lipasee,amylase and soon
Foodstuff
Mile and egg products
Vegetable juices such as rich fat milk powed~baby meal,egg white(vitelling) and so on.
Check extract,coffee,instant tea,protein of fish or pork,protein of potato,soybean or earthpea and so on.
◆Sugar
Maize,maize starch,glucose,pectin,potassium sorbate,maltose and so on Detergent
Emulsifying agent,brightener,dispersant,soda ash,soap powder,ordinary washing powder,high effective washing powder and so on
◆Chemical industry
Dyestuff,pigment,resin,white carbon black,ceramics and so on
Pre-service:
As a good and rich experience supplier, we should offer customer the best quality and best price of the machine.
1. Introduce the suitable product to the customer in detail, answer the question raised by customer carefully.
2. Make the suitabe project as the customer requirement and make sure the machine is suitable for the material.
Sale service:
(1). Ensure product with high quality and pre-commissioning before delivery. (2). Delivery on time. (3). Provide full set of documents as customer’s requirements.
After-sale service:
Provide considerate services to minimize clients’ worries.
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators.
4. Examine the equipment.
5. Take initiative to eliminate the troubles rapidly.
6. Provide technical support.
7. Establish long-term and friendly relationship.
Service commitment:
1. Provide clients one-year warranty to make sure the machine work well.
2. We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely.
3. Send every client a preferential quotation.
