Product Details
Place of Origin: China
Brand Name: JingSu ShengMan
Certification: CE and ISO9001
Model Number: HG
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: USD30,000-USD300,000
Packaging Details: Plywood Cases
Delivery Time: 60-90days
Payment Terms: L/C, T/T
Supply Ability: 10sets
Type: |
Drum Scraper Dryer |
Applications: |
Viscous Materials |
Voltage: |
220v/380v |
Warranty: |
1 Year |
Heating Source: |
Steam,hot Water, Oil, Etc |
Condition: |
100% NEW |
Weight: |
850kh-6150kg |
Material: |
SUS304, SUS304 |
Evaporation Capacity: |
500kg/h |
Installation: |
Engineer Guidance Installation |
Power: |
1.1-8.6 Kw |
Heating Area: |
1.12-10.6 M2 |
Type: |
Drum Scraper Dryer |
Applications: |
Viscous Materials |
Voltage: |
220v/380v |
Warranty: |
1 Year |
Heating Source: |
Steam,hot Water, Oil, Etc |
Condition: |
100% NEW |
Weight: |
850kh-6150kg |
Material: |
SUS304, SUS304 |
Evaporation Capacity: |
500kg/h |
Installation: |
Engineer Guidance Installation |
Power: |
1.1-8.6 Kw |
Heating Area: |
1.12-10.6 M2 |
Working principle of roller scraper dryer
The operation principle of TG series cylinder type Rotary Drum Roller dryer is to let that the materials in liquid or thick liquid state form the thin film on the surface of the cylinder heated through steam or other thermal carrier. For one turn of the cylinder, the film will complete the drying and the product will be removed through the scraper. The exposed surface of the cylinder will contact the materials again to form the film and carry out the drying, It is suitable for drying liquid raw material or sticky material in chemical industry, dyestuff industry, pharmaceutical industry, foodstuff industry, and metallurgy industry and so on.
Technical parameters
size | size of cylinder(mm) | heating area(㎡) | drying capacity(kg/h) | power kw | weight |
HG-600 | 600*800 | 1.12 | 40-70 | 1.1 | 850 |
HG-700 | 700*1000 | 1.65 | 60-90 | 2.05 | 1210 |
HG-800 |
800*1200 | 2.26 | 90-130 | 3.75 | 1700 |
HG-1000 | 1000*1400 | 3.30 | 130-190 | 4.75 | 2100 |
HG-1200 | 1200*1500 | 4.24 | 160-250 | 4.75 | 2650 |
HG-1400 | 1400*1600 | 5.28 | 210-310 | 6.25 | 3220 |
HG-1600 | 1600*1800 | 6.79 | 270-400 | 6.25 | 4350 |
HG-1800 | 1800*2000 | 8.48 | 330-500 | 8.6 | 5100 |
HG-1800A | 1800*2000 | 10.6 | 420-630 | 8.6 | 6150 |
Features of drum scraper dryer
- Lower consumption and operation cost
- Capable to dry different kinds of product
- Stable operation
- Uniform dried product
- Both dryer and calciner, operation Temp. Up to 1000°C
- Heat source can be steam, electricity, coal, natural gas etc.
Pre-service:
As a good and rich experience supplier, we should offer customer the best quality and best price of the machine. We do something as following:
(1). introduce the suitable product to the customer in detail
(2). answer the question raised by customer carefully
(3). make the suitabe project as the customer requirement
(4). make sure the machine is suitable for the material
Sale service:
In order to fulfill the contract smoothly, establish a good cooperative relationship, here's are several points what we must do.
(1). ensure product with high quality and pre-commissioning before delivery
(2). delivery on time
(3). provide full set of documents as customer’s requirements
After-sale service:
Provide considerate services to minimize customers’ worries.
(1). Assist customers to prepare for the first construction scheme.
(2). Install and debuging the drying equipment.
(3). Train the first-line operators.
(4). Exame the drying equipment.
(5). Take initiative to eliminate the troubles rapidly.
(6). Provide technical support.
(7). Establish long-term and friendly relationship with all my customers.
Service commitment:
We provide customers 12-months warranty to make sure the machine work well, and always keep certain inventory level of spare parts, which means the replacements can be sent to you timely. At the same time, we send every customer a preferential and reasonable quotation.
