Product Details
Place of Origin: Changzhou
Certification: CE
Model Number: HG series
Payment & Shipping Terms
Minimum Order Quantity: 1SET
Price: USD 10,000-200,000
Packaging Details: EXPORTING
Delivery Time: 30-90
Payment Terms: T/T
Supply Ability: 10 SETS PER MONTH
Application: |
Food, Chemical ,medicine |
Capacity: |
200-800kg/h |
Product Name: |
Rotary Cyclinder Dryer |
Power Of Motor: |
1.1-8.6 Kw |
Heat Resource: |
Steam |
Effective Heating Area: |
1.12-10.6㎡ |
Power: |
220V/50Hz |
Dimension: |
OPTIONAL |
Application: |
Food, Chemical ,medicine |
Capacity: |
200-800kg/h |
Product Name: |
Rotary Cyclinder Dryer |
Power Of Motor: |
1.1-8.6 Kw |
Heat Resource: |
Steam |
Effective Heating Area: |
1.12-10.6㎡ |
Power: |
220V/50Hz |
Dimension: |
OPTIONAL |
Drum Drying Machine is a kind of professional dehydration equipment specially designed for material dehydration and drying, which is widely used in food industry, chemical industry, pharmaceutical industry, etc. The Drum Flaker Dehydrator is a rotary cylinder dryer with PLC control system. It has a large capacity range from 200-800 kg/h, and customers can customize the dimension according to their needs. The power of Drum Vacuum Dehydrator motor is between 1.1-8.6 Kw. It is an ideal choice for bulk material drying. Drum drying machine can be used to dry a wide variety of materials, such as fruits, vegetables, powder, granules, etc. It has a high degree of automation, reliable performance and environmental protection.
| Technical Parameter | Value |
|---|---|
| Product Name | Rotary Drum Drier, Drum Vacuum Dryer, Drum Flaker Dehydrator |
| Steam Consumption | 100-1575kg/h |
| Effective Heating Area | 1.12-10.6㎡ |
| Power | 220V/50Hz |
| Drum Speed | 0-20rpm |
| Power of Motor | 1.1-8.6Kw |
| Heat Resource | Steam |
| Weight | 850kg-6150kg |
| Producing Material | SS304 316L |
| Heating Method | Electric Heating |
| Capacity | 200-800kg/h |
| size | size of cylinder(mm) | heating area(㎡) | drying capacity(kg/h) | power kw | weight |
| HG-600 | 600*800 | 1.12 | 40-70 | 1.1 | 850 |
| HG-700 | 700*1000 | 1.65 | 60-90 | 2.05 | 1210 |
| HG-800 | 800*1200 | 2.26 | 90-130 | 3.75 | 1700 |
| HG-1000 | 1000*1400 | 3.30 | 130-190 | 4.75 | 2100 |
| HG-1200 | 1200*1500 | 4.24 | 160-250 | 4.75 | 2650 |
| HG-1400 | 1400*1600 | 5.28 | 210-310 | 6.25 | 3220 |
| HG-1600 | 1600*1800 | 6.79 | 270-400 | 6.25 | 4350 |
| HG-1800 | 1800*2000 | 8.48 | 330-500 | 8.6 | 5100 |
| HG-1800A | 1800*2000 | 10.6 | 420-630 | 8.6 | 6150 |
The Drum Vacuum Dryer, also known as the Drum drying machine or Drum Flaker Dryer, is an HG series product made in Changzhou and certified by CE. It comes with a Minimum Order Quantity of 1SET and a Price range of USD 10,000-200,000. The packaging for exporting is provided and the Delivery Time is 30-90 days. The Payment Terms accepted are T/T and the Supply Ability is 10 SETS PER MONTH. The Effective heating area is 1.12-10.6㎡ and the applications are Food, Chemical, and medicine. It has a Drum Speed of 0-20rpm and it is operated in an Automatic mode. The product name is Rotary Cyclinder Dryer.
For technical support and service on Drum Drying Machine, customers can contact us via telephone, email, or live chat. Our team of technical experts are available 24/7 to answer any questions you have and to ensure your product is operating correctly. We also offer troubleshooting, maintenance, and repair services for Drum Drying Machines. Our team will respond quickly to any problems you may encounter, and will work to resolve any issues in a timely manner.
Packaging and Shipping for Drum Drying Machine:
The Drum Drying Machine will be packaged in a wooden crate or box and secured with straps or bands. It will be shipped in a safe and secure manner to ensure it arrives undamaged. The package will also include any accessories or spare parts that were purchased along with the Drum Drying Machine. Delivery time will depend on the destination.
